1500W Power Combiner

The Ideal Diode Power Combiner takes two power sources and combines them into one, creating redundancy without sacrificing efficiency.

A power diode may drop a volt or more when carrying 25 Amps.  This may not sound like a lot, but at 25 Amps this equates to 25W which is a lot of power to get rid of as heat.  The Ideal Diode Power Combiner typically drops less than 100mV at the same current, equating to less than 2.5W.

Features

  • 60 VDC, 25 Amps (1500W max.)
  • Inputs reverse polarity protected and tolerant of transients up to +100V
  • Robust mechanical enclosure with integrated cable strain-relief
  • Conformally-coated PCB for moisture resistance

Highlights

>

High power rating

~

Safety for your UxV

Specifications

Voltage
Operational: +6 to +60 VDC

Absolute maximum: -60 to +66 VDC
Forward power handling1500 Watts continuous
Forward voltage drop200mV maximum (see typical graph below)
Current25 Amps continuous
Connections6 x gold-plated solder pads, with securing points for individual cable strain reliefs
Mounting4 x 3.2mm diameter holes (sized for M3 screws) located on 23 x 43mm rectangle
Quiescent current consumption4mA typical
Operating temperature range-40 to +85°C

Gallery

Resources

Data Sheet

Data Sheet
